115V Non-Submersible Circulator Pump 1/8 HP, 1-1/4" Union NPSM, Canned Rotor Pump with Copper Construction, Direct Replacement for Grundfos 59896776 UP15-29SU/LC
115V Non-Submersible Circulator Pump 1/8 HP, 1-1/4" Union NPSM, Canned Rotor Pump with Copper Construction, Direct Replacement for Grundfos 59896776 UP15-29SU/LC
Description
Item Name: Non-Submersible Circulator Pump Type: Canned Rotor Pump What's in Box: Non-Submersible Circulator Pump *1 Item Condition: Brand New Part Number Direct replacement of UP15-29SU/LC 59896776 Specification Manufacturing Data Type:Canned Rotor with Integrated Pump and Motor Body: Stainless Steel & Copper Axial Bearing: Carbon Shaft & Radial Bearings: Ceramic Impeller: Corrosion-resistant Composite PES Flange Standard: USA Threaded Connection: 1-1/4" Union (NPSM) Port-to-Port Length: 5.87 In Certification: CE Electrical Data Voltage: 115 Volts Amperage: 0.42-0.75 Amps (Max at speed 3) Main Frequency: 60 HZ Phase: 1 (Need no additional motor protection required) Poles: 2 Max Power Input: 87 Horse Power: 1/8 HP Run Capacitor: 10 µF, 180V Insulation Class (IEC 85): Class F Liquid Data Max Pressure: 145 Psi Max Ambient Temperature: 104°F (176°F with liquid at 176°F) Max Liquid Temperature: 230 ℉ / 110 ℃ Min Liquid Temperature: 36 ℉ / 2.2 ℃ Max Flow: 20.5 GPM Max Head: 9.7 Ft Offering with better materials, ShenBrala is an economical direct replacement pump of GRUNDFOS UP15-29SU/LC with robust copper and stainless steel construction, the ideal choice for continuous operation in demanding environments Why ShenBrala Choose ShenBrala for unmatched durability, efficiency, and reliability. With a rugged stainless steel casing and 1/8 HP power, it effortlessly handles high flow rates up to 20.5 GPM and pressures of 145 psi. Built to thrive in extreme temperatures (36°F to 230°F) and protected against dust and splashes, ShenBrala’s IP44-rated design is ready for any challenge. Backed by over 100 years of expertise and a 12-month warranty, ShenBrala is the pump that won't let you down. Invest in quality that lasts—Choose ShenBrala!
Item Details
Pickup Location
4031 Market Center Dr Suite 303
North Las Vegas, NV, 89030
Quality
brand
ShenBralaEstimated Retail Price
$202.77
color
Redsize
𝐒𝐭𝐚𝐧𝐝𝐚𝐫𝐝Buyers Premium
15%
Inventory Number
1047935733
Found in
Features
- 𝐏𝐚𝐫𝐭 𝐍𝐮𝐦𝐛𝐞𝐫: Direct replacement for Grundfos UP15-29SU/LC 59896776
- 𝐌𝐚𝐧𝐮𝐟𝐚𝐜𝐭𝐮𝐫𝐢𝐧𝐠 𝐃𝐚𝐭𝐚: ShenBrala circulator pump features a canned rotor with an integrated pump and motor. Made from copper, it uses carbon axial bearings, ceramic shaft and radial bearings with a corrosion-resistant composite PES impeller. It has a 1-1/4" union connection (NPSM) and a 5.87" port-to-port length
- 𝐄𝐥𝐞𝐜𝐭𝐫𝐢𝐜𝐚𝐥 𝐃𝐚𝐭𝐚: The pump operates on 115V during 0.42-0.75A (max at speed 3). It runs on 60Hz with a 1-phase motor, requiring no additional protection. Featuring 2 poles, offering 1/8 HP with power input of 87W; The run capacitor is 10 µF, 180V, the circulator meets Class F insulation (IEC 85)
- 𝐋𝐢𝐪𝐮𝐢𝐝 𝐃𝐚𝐭𝐚:This pump offers great performance with a max pressure of 145 Psi and can operate in ambient temperatures up to 104°F (up to 176°F when the liquid temperature is also 176°F). It handles liquids with temperatures ranging from 36°F to a maximum of 230°F. With a max flow rate of 20.5 GPM and a max head of 9.7 feet, the ideal for high-demand applications
- 𝐖𝐨𝐫𝐫𝐲 𝐅𝐫𝐞𝐞: ShenBrala offers an economical direct replacement of GRUNDFOS UP15-29SU/LC 59896776, Each pump is 100% factory-tested for quality. With over 100 years of expertise, ShenBrala provides a 12-month after-sales service for peace of mind
