3HP Electric Motor 3450 RPM Farm Duty Motor, Single Phase Motor 145T Frame 230V 7/8"Shaft Diameter 60HZ CW/CCW TEFC

Features

• Agricultural Single Phase Motor: Maximum speed of 3450 RPM, synchronous speed of 3600 RPM, POLE - 2, FRAME -145T, ENC -TEFC, HZ: 60HZ, Voltage: 230V, AMP: 12.4A, RPM: 3450, IP - 55.
• Housing Material: Rolled steel shell. Adopt S1 continuous working system, safe and durable, long service life, INS - F, Rotation - CW/CCW, Shaft diameter - 7/8", Shaft length - 2.25".
• High Working Efficiency: Compact structure and small size, electric motor can run at the maximum speed of 3450 rpm, high working efficiency; There are lots of heat sinks, so it has huge heat sinks.
• Fully Enclosed Fan: The TEFC electric motor with large fan at one end, even in wet and dusty conditions, cools the motor during long runs, thus reducing energy costs, reducing operating temperatures and increasing service life.
• Widely Application: 3HP electric motor widely used in industrial and agricultural production, transportation, commercial and household appliances and other fields. For example, water pump, agricultural machinery and so on
