ADKUN 34117 Waste Ball Kit Compatible with Thetford Aqua Magic Style II, Style Lite, Style Plus Toilet, Replaces 34117,34120,34106

Package Includes: 1 x Waste Ball 2 x Waste Ball Seals, 4 x U-cup seals 4 x Closet Flange Seals Compatible Models: The waste ball kit compatible with Thetford, Style II, Style Plus, Style Lite and Residence Toilets Replaces Numbers: 34117 34120 34106 42050 42072 Note: Keep toilet and water pipes closed and empty before installation, remove toilet before installation work （This part is compatible with the following toilet models. ) 42050, 42051, 42052, 42053, 42054, 42055, 42056, 42057, 42058, 42059, 42060, 42061, 42062, 42063, 42064, 42065, 42070, 42071, 42072, 42073, 42074, 42075, 42076, 42077, 42104, 42105, 42106, 42107, 42117, 42118, 42119, 42120, 42153, 42154, 42155, 42156, 42157, 42158, 42159, 42160, 42161, 42162, 42163, 42164, 42165, 42166, 42168, 42169, 42170, 42171, 42172, 42173, 42174, 42175, 42176, 34420, 34421, 34422, 34423, 34424, 34425, 34427, 34428, 34429, 34430, 34431, 34433, 34434, 34435, 34438, 34439, 34440, 34441, 34442, 34443, 34445. Needed： 1x Towel 1x Plastic trash bag 1x Pliers 1x Phillips-head screwdriver 1x 3/8" Socket and wrench 1x 1/2-inch wrench Remove the old waste ball: 1. Place the toilet side on the floor with the pedal upward. 2. Hold the bowl and grasp the front lower side of the pedal. Pull the pedal up quickly. 3. Remove the drive arm screws. Pull out the waste ball drive arm. 4. Keep the toilet upright. Remove the screws between the bowl and the base with a 3/8-inch socket. 5. Fix the base, rotate the bowl counterclockwise until it is free, and lift it away from the base. 6. Remove the waste ball seal. And then discard. 7. Remove the seal retainer. 8. Push out the waste ball (the end opposite to the drive arm), remove it from the base and discard it.
