DB Electrical 430-22155 Marine Starter 15HP Compatible with/Replacement for Yamaha F15CELH 2007 2008, F15CESH 2007 2008 2011, F15CMLH 2007 2008, F15CPLH 2007-2011, F15CMSH 2007 2008 69A-43880-00-00

Features

• Specs: Tilt & Trim Motor, Voltage: 12, Rotation: RE, Teeth: 9, Dimension: Replacement Unit:, OD: 47.3mm, Shaft OD: 8.6mm , Length: 134mm, Terminal Size (2): 6.4mm, Shaft: 9-Tooth, Notes:, 42.5" Harness, Shaft Protrudes From Housing, Gear Shaft 28mm OAL (Exposed From Surface), (4) 5.8mm ID Unthreaded Mtg. Holes, Brief: Yamaha 15-20HP Outboard Motors 2001-17
• Replaces OEM Numbers: ARROWHEAD: 430-22155, J & N: 430-22155, Yamaha: 69A-43880-00-00, 69A-43880-01-00
• Compatible With/Replacement For: YAMAHA F15CELH 2007-2008, F15CESH 2007-2008, F15CESH 2011-2011, F15CMLH 2007-2008, F15CMSH 2007-2008, F15CPLH 2007-2008, F15CPLH 2009-2011, F15LPHA 2012-2017, F15PLH 2001-2007, F15PLR 2001-2007, F20LPA 2012-2017, F20LPHA 2012-2017, F20PLH 2007-2008, F20PLH 2009-2011, F20PLR 2007-2008, F20PLR 2009-2011
• 1-year warranty protects you after your purchase. We're confident that our products will work flawlessly once installed in your vehicle. But in a rare case that it does not, we'll replace it anytime within one year of your order. If you have a problem, we will take every step to assist you, contact us for a replacement.
• 100% New Aftermarket Tilt & Trim Motor built to meet OEM specifications
