Oreq MPPT Solar Controller, Waterproof Intelligent Battery Regulator, 24-85V Solar Panel System (400W) with Display

Specification: Item Type: Solar Battery Charge Controller Product Size: Approx. 120 x 80 x 40mm / 4.72 x 3.15 x 1.57in Efficiency: 95% Noise: <55dB Uses: Solar street light controllers, solar chargers, solar electric bicycle, solar electric tricycles, solar toy cars, household solar panels, solar monitoring and other usage scenarios Weight: 485 g / 17.1 oz(approx.) Applicable battery All kinds of batteries (charging voltage between 24-85V) Suitable for photovoltaic panel parameters Open circuit voltage 18V-55V Maximum power voltage 17V-55V Charging module PV input power 200W/300W/400W PV input starting voltage 18V-55V PV input tracking voltage 17V-55V Output to battery voltage 24-85V (adjustable) Output to battery current Maximum 15A Load loss 0.35W Voltage regulation 1% Load regulation 1% Protection module Battery undervoltage protection Have Battery terminal short circuit protection Have Battery non reverse protection None Overcurrent Protection Have Temperature protection Have Protection class IP66 Operating temperature -40℃+65℃ 1.OVERHEATING Package List: 1 x Solar Battery Charge Controller 1 x User Manual
