S8910U3000 Universal HIS Module, Compatible with Honeywell S8910U3000 Hot Surface Ignition

S8910U3000 Universal Hot Surface Ignition Module Direct Replacement for Resideo, Robertshaw & White-Rodgers HSI Controls The S8910U3000 Universal Hot Surface Ignition Module is a professional-grade replacement control designed for field technicians. This versatile module replaces a wide range of hot surface ignition modules from major manufacturers including Resideo, Robertshaw, and White-Rodgers, making it an essential part for HVAC/R service technicians' inventory. Key Features & Benefits: Universal Compatibility: Direct replacement for numerous hot surface ignition modules from Resideo, Robertshaw, and White-Rodgers. Supports both natural and LP gas systems. Flexible Configuration: Adjustable via DIP switches for ignition trials (1 or 3), trial time (4 or 7 seconds), igniter warm-up (7, 17, 34, or 45 seconds), and local/remote flame sensing. Complete Installation Kit: Includes White-Rodgers adapter, Robertshaw ground lead, five quick-connects (four 1/4" and one 3/16"), and nine wire labels for proper identification. Safe & Reliable Operation: Features 32-second prepurge, flame failure response within 1.5 seconds, and safety lockout after maximum retries. LED status indicator for easy troubleshooting. Wide Application Range: Designed for use in central heating furnaces, commercial cooking equipment, agricultural heaters, industrial heating systems, and pool heaters with 120V hot surface igniters. Robust Construction: Operates in extreme temperatures from -40°F to +175°F (-40°C to +79°C). Designed for 60Hz applications. Professional Installation: Must be installed by trained, qualified service technicians only. Not for DIY installation. Technical Specifications: Control Voltage: 24V, 60Hz Hot Surface Igniter Voltage: 120Vac, 5A maximum Valve Contact Rating: 2A Current Draw: 0.4A plus valve load Prepurge Time: 32 seconds Flame Failure Response: 1.5 seconds maximum Operating Temperature: -40°F to +175°F (-40°C to +79°C) Ignition Trials: Configurable for 1 or 3 trials Ignition Trial Time: Configurable for 4 or 7 seconds Applications: Central heating furnaces Commercial cooking equipment Agricultural heating systems Industrial heating applications Pool and spa heaters Other appliances using 120V hot surface igniters What's Included in the Package: S8910U Universal Hot Surface Ignition Module White-Rodgers adapter Robertshaw ground lead Four 1/4" female .032 quick-connects One 3/16" female .032 quick-connect Nine wire labels Installation instructions Compatibility: This module replaces numerous specific models including (but not limited to): White-Rodgers 50E47 and 50F47 series Robertshaw HS780 series Resideo S89, S890, S89H, S89C series Complete compatibility list available in product documentation. Always verify compatibility before installation. Important Installation Notes: WARNING: Installation must be performed by trained, qualified service technicians only WARNING: Not for use with intermittent pilot ignition, direct spark ignition, 24V element, or 240V input/120V element systems Always verify DIP switch settings against cross-reference tables before installation Ensure proper grounding between module and main burner for reliable flame detection Module must be protected from water, moisture, corrosive chemicals, excessive dust, and grease Professional Use Only: The S8910U3000 is designed for professional HVAC/R technicians. Proper installation requires understanding of gas appliance controls, electrical systems, and safety protocols. Always follow local codes and manufacturer guidelines when installing or servicing gas ignition systems. Note: This product is tested and calibrated under controlled conditions. Some performance variations may occur in different environmental conditions. Always verify system operation after installation.
