TaiShi P80 2 Spool Hydraulic Reversing Valve, Stainless Steel, 21gpm, 25MPa, 5 Ports, Joystick Control

Description: P80 multi-way reversing valve flow 80L / MIN, with high working pressure, compact structure, safety valve and overload valve opening and closing performance, good versatility and so on. Can be widely used in construction machinery, special vehicles, sanitation machinery and drilling machinery. Specification: Model: P80, 2 Spool Nominal flow: 21gpm (80l/min) Max. working pressure: 25MPa (3625PSI) Relief valve pressure: 17MPa, Adjustable Applicable temperature: -20～80℃ Max operating pressure P = 3600psi (250 bar); T = 150psi (10 bar); A , B = 4300psi (300 bar) P, A, B ports: G 1/2" T, N port: G 3/4" Package size: 50×30×24cm Gross weight: 10.3kg Features: O function, spring reset Open center system (pump-to-tank flow) Flexible shaft + one control and two handles (flexible shaft 1.5m) All spools are standard double acting with spring return in neutral position Package Includes: 1× 2 Spool Valve + Cables + Joystick
