YIDOFENG Photoelectric 3D Touch Probe Trigger Sensor Edge Finder,Accuracy 0.001mm,with Ceramic Probe, X,Y,Z Axis Measurement Centering Rod Touch Probe Tool Dividing Rod to Find CNC Lathe Center

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 【Specifications】 MMP25 3D Light Edge Finder supports X,Y,Z three-coordinate/direction measurement,reciprocating positioning accuracy ≤ 0.001mm; Probe direction: ±X ±Y +Z; Probe safety stroke: X.Y plane ±15°; Z direction +5mm; Trigger life:5,000,000 times;Probe Material:Ceramics (NOTE:Powered:3.6V 14250 lithium ,but not included)
• 【Measurable material】3D Edge Finder can measure insulation materials such as metal, electric wood, wooden boards, plastics, etc.The principle of conductivity is not required. The workpiece material and the machine tool spindle are not conductive and can also be measured
• 【Accuracy ≤ 0.001mm】Higher alignment accuracy, repeatability up to 0.001MM: the edge finder adopts a sturdy sealed shell, and the body is made of stainless steel with a ceramic ball head. It has good structural stability, excellent performance, and high measurement accuracy
• 【How to use】(1)After mounting the 3D edge probe on the machine, the spindle is rotated to check the runout of the probe ball;(2)After detecting the runout of the probe ball, adjust it with four M3 fixing screws until it reaches a runout of 0.01mm.(3) Tighten the screws and the probe is ready for use.
• 【Package included】1PC 3D Electronic Edge Finder MMP25
