Zouzmin R8-FMB22 BAP400R Face Mill APMT1604PDER Carbide Inserts

Additional Details from the Manufacturer

This item information is coming from the manufacturer. Some of the details may vary from the Nellis Auction listing. Please check the Quality Rating and Notes for information specific to this listing

More features

• 【APMT1604PDER Carbide Milling Inserts 】HRC15°-55°，Dual-edge , Tin Nano blue Coated，blade length=0.63", I.C(d): 0.366", Thickness(s): 0.187",Hole(d1): 0.173",Nose radius(r): 1/32",Nose Angle: 85°,Relief Angle: 11°,Good for both finishing and roughing.
• 【BAP400R 50-22-4T Face milling Cutter】40Cr MnTi ,1.96" height and face diameter. Interface diameter=22mm/0.86". Through heated and quenched, solid hard with good cushioning effect, Screw down insert, screw size=M4*9, wrench=T15.
• 【R8 FMB22 Face Mill Arbor】Made from alloy steel hardened to HRC 52-56,For shoulder milling, face milling and slotting,7/16-20 thread on the draw bar，Positive rake 90Degree, right hand cut. Shank Size: R8.
• 【Advantage】High vibration-absorbing performance, improve the surface finish of the workpiece, Great for shoulder milling, face milling and slotting.Suitable for Hardened steel, as well as various die steel, stianless steel, high temperature alloy steel and other high hardness materials。
• 【Package list】1pcs 2" R8-FMB22 face mill arbor + 1pcs 400R 50-22-4T Milling cutter + 10pcs APMT1604PDER carbide milling inserts + 1pc T15 Wrench
